Commodity PCBs in 3 Days

Layer Options

• 2, 4, and 6 layers
• All boards are built with a fixed 6-layer stack-up

Materials & Finish

• Thickness: 0.062"
• High Temp FR4
• Copper Weight: 1 oz on all layers
• Soldermask: Green
• Silkscreen: White (top and bottom as applicable)
• Surface Finish: Silver

Design Rules

• Minimum Mechanical Drill Size: 0.008"
• Minimum Trace Width: 0.008"
• Minimum Trace Spacing: 0.008"

• Individual boards only – no panelization accepted
• 100% netlist test on all boards
• Minimum order quantity: 2 PCBs
• Orders accepted only in multiples of 2
• No gold fingers
• No edge plating
• No castellations
• No customization (stack-up, finish, mask, copper, or thickness)
• Standardized pricing with automated online sales booking
• Credit card payment required at time of order

• Day 1 cutoff: Orders received by 10:00 AM CST enter production same day
• Day 3 shipment: Boards ship by close of business on Day 3

• Daily production capacity is limited to a 10" × 16" manufacturing panel
• Once the panel is fully populated, no additional orders are accepted for that day
• Orders beyond the daily panel limit are automatically scheduled into the next day’s build
• Order is booked and scheduled at the time of order, based on available capacity
